Large customer access solution

Overview

Huachentel’s HC-DM-DXC4/8/16 digital cross-connect device DXC allow maximum flexibility for time-slot crossing. The connection matrix connects any incoming 64Kbps timeslot to any outgoing 64Kbps timeslot. HC-DM-DXC4/8/16 can be used in the application like drop-and-insert, distribution and collection.

The main applications are found in the local switching of Nx64k leased line connections, and the concentration of Nx64k services onto 2 Mbps E1 circuits. This solution is particularly useful for smaller concentration points where the investment in backbone switching equipment might be too high.

Feature

Provide programmable non-blocking cross-connection of 64K channels

4/8/16 E1 interface

Can be managed or CLI through the serial port on the back-panel

Any arbitrary combination of 64k time-slots

Specification

256 x 256 for HC-DM-DXC4

512 x 512 for HC-DM-DXC8

1024 x 1024 for HC-DM-DXC16

Optical interface:

Line code: 1B1H

Line Data rate: 33.792 Mbps

Transmission power: > -10dBm (LD)

Receive sensitivity: < -36dBm (Pe=1 x 10^-10)

Connector: FC/SC optional

E1 interface:

Comply with ITU-T G.703 standard

Line code: HDB3

Rate: 2048Kbps±50ppm

Connector: BNC/SMB for 75Ω unbalance, RJ45 for 120 Ω for balance

Impedance: Balance/unbalance optional

Console port:

RS232 console port for an ASCII terminal

Date format: 9600bps, 8-bit data, 1-bit stop flag

Function: software upgrade, loop configuration, status monitoring

Connector: RJ45

Others

Supply both 220V AC and -48V DC

Power dissipation: < 8W

Dimension: 19” 1U

Operating Temperature: -5°C~+45°C

Store Temperature: -20°C~+70°C

Relative humidity: 5% ~ 95% no coagulation
